Specification
|
Module size |
Φ17.5 mm |
||
|
Fingerprint |
working voltage |
DC 3.3V |
|
|
Working current |
＜40mA @ 3.3V |
||
|
Touch |
Working voltage |
DC 3.3V |
|
|
Standby current |
＜10uA @ 3.3V |
||
|
Effective level |
Highly effective |
||
|
Image |
Resolution |
508 DPI |
|
|
Grayscale |
256 levels |
||
|
Time |
Collection time |
＜250ms |
|
|
Search time |
0.9 second （1:100 average value） |
||
|
Power-on time |
＜100ms |
||
|
Matching method |
1:1 comparison / 1:N search |
||
|
Safety level |
5 levels（from low to high：1,2,3,4,5） |
||
|
Storage capacity |
100 pieces |
||
|
False acceptance rate (FAR) |
＜0.001% (when the safety level is 3） |
||
|
False rejection rate (FRR) |
＜1.0% (when the safety level is 3） |
||
|
Communication interface |
UART（3.3V TTL logic level） |
||
|
Communication rate |
UART |
(9600*N)bps ,N=1,2,4,6,12(default N=6) |
|
|
Operating ambient |
Temperature |
-25℃ ～ +75℃ |
|
|
Relative humidity |
40％RH ～ 85％RH ( no condensation) |
||
|
Storage ambient |
Temperature |
-40℃ ～ +85℃ |
|
|
Relative humidity |
＜85％H（no condensation ） |
||
