Features
*Based on MediaTek Single Chip Architecture (MT3339).
*ARM7 based application processor
*High sensitivity: -165dBm tracking
*L1 frequency, C/A code
*Channels: 66 acquisition, 22 simultaneous tracking
*Low power consumption: 26mA @ acquisition, 20mA @ tracking
*Cold/Warm/Hot start time: <35/<33/<1 seconds
*Maximum update rate up to 10Hz
*GPS data interface: TTL level serial port
*Support NMEA 0183 standard V3.01 and backward compliance
*Support SBAS – WAAS, EGNOS, GAGAN and MSAS
*Dimension：16mm x 16mm x 6.7mm
*RoHS compliant
*Advanced software features
-AlwaysLocate TM advanced location awareness technology
-EPO TM orbit prediction
-Supports logger function (LOCUS)
