Features
- Based on MediaTek Single Chip Architecture (MT3337).
- ARM7 based application processor
- High sensitivity: -165dBm tracking
- L1 frequency, C/A code
- Multi-tone active interface canceller (MTAIC)
- Channels: 66 acquisition, 22 simultaneous tracking
- Low power consumption: 26mA @ acquisition, 22mA @ tracking
- Cold/Warm/Hot start time: <35/<34/<1 seconds
- Maximum fixed update rate up to 5Hz
- GPS data interface: TTL level serial port
- Support NMEA 0183 standard V3.01 and backward compliance
- Support SBAS – WAAS, EGNOS, GAGAN and MSAS
- Dimension：11.5mm x 11.5mm x 2.15mm
- SMD TYPE
- RoHS compliant
- Advanced software features
AlwaysLocateTM advanced location awareness technology
EPOTM orbit prediction
Supports logger function (LOCUS)
